Plug in Panel Mounting Spring Cage Clamp Terminal Block Connector 24A/800V

Overview

Basic Info.

Model NO.	JUT3-1.5
Shape	Square
Interface Type	AC/DC
Certification	BS, UL, VDE
Brand	Utl
Standard	IEC 60947-7-1
Wire Range	24-10 AWG
Terminal	Ns32 G Type or Ns35 U Type
Color	Grey or Customized
Transport Package	Export Carton
Specification	24-10 AWG
Trademark	UTL
Origin	China
HS Code	85369090
Production Capacity	2000000PCS/Year

Product Description

Brief Introduction
1) The insulating shell is made of imported engineering plastic polyamide (nylon) 66 with high mechanical strength, good electrical characteristics and excellent elasticity.
2) The conductive strip is made of red copper plated with matte tin, and the line-pressing frame is made of brass plated with nickel, which has good electrical conductivity.
3) Flame retardant grade UL94 V0.
4) The pull-back spring terminal is connected from the upper line, the wire entry port is set at the top of the terminal, and the wiring groove can be installed close to the terminal block, which can make full use of the space of the electrical cabinet, improve the wiring density, and provide a good angle for observing the wiring position, which is convenient for wiring. It also has a clear marking system, the largest wiring capacity, and a flexible plug-in bridge system.
The fuse-type terminal block adopts segmented hanging wall to connect to the G-type fuse, which is very convenient to operate. The shell adopts a fully enclosed type, which is safe and reliable. Terminals with an illuminated display give an on-off signal for the fuse. The current of this type of terminal is determined by the installed fuse, and the voltage is determined by the selected illuminated terminal display.5) The product has universal mounting feet, which can be easily and quickly installed on the NS35 rail.
Product overview

Product pictures

Application

Name	Date	Unit
Number of connection points	2
Number of potentials	1
Color	gray
Length	48.5	mm
Width	4.2	mm
With U-rail height	36.5	mm
Pollution degree	3
Insulation material group	I
Rated surge voltage	6	KV
Meet standard	IEC60947-7-1
Rated voltage	500	V
Nominal current	17.5	A
Meet standard	UL1059
Rated voltage	600	V
Nominal current	10	A
Min.connection capacity for solid wire	0.14/26	mm²/AWG
Max.connection capacity for solid wire	2.5/14	mm²/AWG
Min.connection capacity for strand wire	0.14/26	mm²/AWG
Max.connection capacity for strand wire	1.5/16	mm²/AWG
Line direciton	vertical to terminal
Strip length	9	mm
Insulation material	PA66
Flame-retarded Rating	UL94 V-0
certification
